Cooling capacity: 180000 Btu/h; 53kW
Cooling input: 16.7 kW
Cooling EER: 10.8 Btu/ h.W
Heating capacity: 191000 Btu/h; 56kW
Heating input: 17.2 kW
Heating COP: 11.1 Btu/ h.W
Airflow (indoor side): 7000 CFM
External static pressure: Default 110; 0 ~ 325 Pa
Max power input: 25 kW
Max current: 46.1 A
Compressor type / quantity: Scroll / 2
Compressor brand: Copeland
Indoor fan type / drive type: Centrifugal / Belt
Outdoor fan type / drive type: Axial / Direct
Wired controller: KJR-12B/dP(T)-E
Centralised controller (optional): Yes
Sound pressure level: 76.9 dB(A)
Ambient temperature (cooling): 10°C ~ 46°C
Ambient temperature (heating): -9°C ~ 24°C
Net dimension (WxHxD): 1965 x 1230 x 1130 mm
Net / Gross weight: 492 / 512 kg
